APPLICATIONS
• 10GBASE-LR/LW
• CWDM Networking
FEATURES
• 40 km transmission
• 14 dB link budget
• 10 low-band CWDM wavelengths (?): 1271 nm to 1451 nm
• Hot pluggable SFP+ MSA form factor
• Data rate up to 11.1 Gb/s
• Uncooled DML Laser
• PIN receiver
• Single 3.3Vpower supply
• Low power consumption
• Duplex LC optical receptacle
• Digital Optics Monitoring (DOM)
• RoHS-6 compliant (lead-free)
• Operating Case Temperature:
Standard: -40°C to 85°C
