SFP BIDI, 100/155Mbps, SM, 20km

TX/RX=1310/1550nm, 13 dB, LC

Product nr: SFP-FE-100BX-U-10

Description

APPLICATIONS
• single fiber options 1310/1550
• 100Base Ethernet

• FTTx

FEATURES
• 20km transmission on SM fiber
• Hot-Pluggable SFP footprint
• LC optical interface
• compliant to SFP MSA and SFF-8472

Technical info

Form factor	SFP
Protocol / bit rate	Fast Ethernet
Media type	Single fiber
Reach (dB)	13
Reach (km)	20
Wavelength (nm)	1310/1550
Laser Type	FP (Fabry-Perot)
Detector type	PIN
Line Modulation	NRZ
DDM	No
Connector	LC Simplex
Safety class	Laser Class 1
Operating temperature range	0°C - +70°C (Standard)
Temperature range, storage	-40°C - +85°C
Customs classification codes	ECCN: 5A991 HS: 8517.62.0090
