SFP+, 10G Ethernet, DDM, 300m

850nm, 4dB, MM, Check Point

Product nr: SFP-10GE-SR-CP+

Alt. varenr: CPAC-TR-10SR-C

Product

Description

APPLICATIONS
• 10GBASE-SR

FEATURES
• Up to 300 m transmission at 850 nm on OM3, 2000 MHz*km
• Hot-Pluggable SFP+ footprint LC Optical Transceiver
• Small Form-Factor Pluggable (SFP) MSA compatible
• SFF-8472 Digital Diagnostic Function

Technical info

Product information

Form factor	SFP+
Protocol / bit rate	10 Gigabit Ethernet 10G Fibre Channel SDH STM-64 OTN/G.709/G.sup43 OTU2(e) CPRI/OBSAI 1.228 - 3.072 Gbps CPRI/OBSAI 4.915 - 9.830 Gbps
Media type	Multimode
Reach (dB)	4
Reach (km)	0,3
Wavelength (nm)	850
Compatibility	Check Point
DDM	Yes
Connector	LC Duplex
Safety class	Laser Class 1
Operating temperature range	0°C - +70°C (Standard)
Temperature range, storage	-40°C - +85°C
